Belvedere

The Belvedere can transform from a contemporary home care bed, to a clinically advanced nursing care bed to accommodate clients’ health needs quickly and easily. As a contemporary home care bed with a configurable low foot end for increased resident visibility, the Belvedere is almost unrecognisable as a nursing care bed.

As resident’s healthcare needs change, the Belvedere seamlessly transforms into a clinically effective nursing care bed. Simply remove the low foot end and replace with a high foot end, turn the headboard around to reveal the side channels and add the full-length side rails, the Belvedere now offers complete in-bed safety for the occupant. The beds are supplied with finger kits and side rails can be purchased separately.

Please note other wood finishes are also available, including Beech, Walnut, Elm and Ash. Please contact your local sales lead or our customer services team for a quote.

Please see the Related Products section at the bottom of page for side rail and accessory information.


Key Features

  • Four section profiling bed
  • Available in 6 wood finishes
  • Configurable head/footboards
  • Intuitive 9 button handset

   Platform Height (Min – Max) 30-77cm

   Platform Length 200cm

   Platform Width 90cm

   User Weight Capacity 155kg (24st)

Product Details

Technical Specifications

Explore detailed specifications and key information about this product, including dimensions, performance, and essential features—helping you choose the right mobility solution with confidence.

Description

• The Belvedere is a four-section electrically, fully profiling nursing care bed

• To suit all decor and interiors, the Belvedere is available in 6 wood finishes and a wide range of head board pad colour options

• Configurable head and foot ends allows the bed to be transformed from a stylish home care bed into a nursing care bed

• Slatted bed platform for easy cleaning and durability

• Full length integral side rails offer complete in-bed safety

• The unique dipped design allows for easier ingress and egress for the resident; reducing pressure on the back of the legs

• No visible side rail channels when in the home-style variance

• Low footboard supplied as standard; sitting just above the mattress improves resident visibility

• Intuitive and easy to use 9 button handset. The lightweight handset can be locked out to ensure vulnerable patients’ safety

• 3 year warranty as standard

• Low bed height of 30cm for improved falls prevention

• 4 castors with individual brakes for improved safety and stability

• Auto contour feature allows simultaneous backrest and knee break adjustments, preventing patients sliding down bed and reducing friction and shear

• High bed height of 77cm supports carers during daily nursing duties without the need to bend

• Reverse Trendelenburg function to assist and improve blood circulation to the lower body and improve respiration

• Cardiac chair position provides a more comfortable sitting position for patients, allowing them to self-feed and enabling a better view of the surroundings. This position also reduces pressure in the sacral area compared with the backrest raised alone

• Full compliance to EN60601-1-2-52 and EN60601-1-11

• Reverse Trendelenburg up to 15 degrees

Additional information

Options Available

Low Foot Board in Light Oak without Side Rails – BELV/LFE/LOAK, High Foot Board in Odessa Oak without Side Rails – BELV/HFE/ODOAK/FSR

Product Specifications

Spec type BELV/LFE/LOAK BELV/HFE/ODOAK/FSR
Backrest Adjustment Electrical Yes Yes
Reverse Trendelenburg 17° 17°
Trendelenburg Option available -15° Option available -15°
Knee Break Adjustment Electrical Yes Yes
Platform Height (Min – Max) 30-77cm 30-77cm
Platform Length 200cm 200cm
Platform Width 90cm 90cm
Product Weight 145kg 145kg
Safe Working Load 192kg (30st) 192kg (30st)
User Weight Capacity 155kg (24st) 155kg (24st)

Downloads

User Manual – PDF Download
Sales Brochure – PDF Download
